ADC SAMRH707x - ADC for SAM RH707x Radiation-Hardened MCU
When to use:
When to use:
- SAM RH707x target device (radiation-hardened for aerospace/space applications)
- Satellite telemetry, spacecraft instrumentation, or nuclear facility monitoring
- Extended temperature range and high-reliability requirements
- Fault detection and ECC (Error Correcting Code) features needed
- Radiation-tolerant ADC for harsh environments (space, military, nuclear)
When NOT to use:
- Commercial SAM device (SAME5x, SAME7x) — use ADC SAME5x or AFEC SAM7x blocks
- Standard environmental conditions — RH707x is aerospace-grade, higher cost
- dsPIC target — no SAM RH707x peripheral available
12-bit resolution required — limited to 12-bit SAR ADC
Device Support
- SAM RH707x
Features
| Feature | Specification |
|---|---|
| Resolution | 12-bit SAR ADC |
| Speed | Up to 1 Msps |
| Channels | Multiple analog inputs (device dependent) |
| Reliability | Radiation hardening, ECC, fault detection |
| Operating Temperature | Extended range for space applications |
Examples
- Satellite telemetry and control
- Space instrumentation
- Nuclear facility monitoring
- High-altitude aviation systems
- Military/defense applications
Related Blocks
- ADC SAME5x - For commercial SAM E5x devices
- AFEC SAM7x - For SAM E7x/S7x/V7x families
Configuration
Similar sequence-based configuration to SAM E5x ADC block, with additional reliability features and radiation-aware timing parameters.
